CR380(LED)Surface Mounts Singal Door Locks
- Holding Force380kg(800Lbs)
- Input Voltage12VDC/24VDC
- Current12V/480mA or 24V/240mA
| Holding Force | 380kg(800Lbs) | Suitable | Wooden door,Glass door,Metal door,Fireproof door |
| Input Voltage | 12VDC/24VDC | Operating Temp | -10~+55℃(14-131F) |
| Current | 12V/480mA or 24V/240mA | Humidity | 0~90%(non-condensing) |
| Cover Finish | Anodized aluminum | LED | Red(unlocked) Green(Locked) |
| Lock Finish | Zinc | G.W.(kg) | 2.67 |
| Armature Plate Finish | Zinc | Size(mm) | 285L*55W*29H |
| N.W(kg) | 2.53 |
