CR280(LED)Surface Mounts Singal Door Locks
- Holding Force280kg(600Lbs)
- Input VoltageDC12V/DC24V
- CurrentDC12V/460mA DC24V/230mA
| Fail-safe | Power off to Open | Service life | more than 500,000 times |
| Lock body size | 250*48*27 mm | Opening signal of 12VDC power supply | |
| Suction plate size | 18*38*11 mm | Operating humidity | 0-90%(no condensing) |
| Weight | 2KG | Certificate | CE and MA(China Public Security Office) |
| Working voltage | 12VDC | Armature Plate Finish | Zinc |
| rking current | 150mA | Suitable | Wooden door,Glass door,Metal door,Fireproof door |
| Static current | 20mA | Operating Temp | -10~+55℃(14-131F) |
| Electric control unlocked voltage | 6~18VDC/AC | Humidity | 0~90%(non-condensing) |
| Opening delay time | 6s (locking automatically if the door is not opened within 6 seconds) | LED | Red(unlocked) Green(Locked) |
| Alarm time | 3min | Working mode | magnetic induction |
| Extension length of locking tongue | 20mm |
CR280(LED)
| Signal output | CR280 Without Signal CR280-S With Signal output | Armature Plate Finish | Zinc |
| Holding Force | 280kg(600Lbs) | Suitable | Wooden door,Glass door,Metal door,Fireproof door |
| Input Voltage | DC12V/DC24V | Operating Temp | -10~+55℃(14-131F) |
| Current | DC12V/460mA DC24V/230mA | Humidity | 0~90%(non-condensing) |
| Cover Finish | Anodized aluminum | LED | Red(unlocked)，Green(Locked) |
| Lock Finish | Zinc |
