CR180(S) Surface Mounts Singal Door Lock
- Holding Force180kg(350Lbs)
- Input VoltageDC12V/DC24V
- Current12V/300mA DC24V/150mA
| Signal output | CR180 Without Signal CR180-S With Signal output | Armature Plate Finish | Zinc |
| Holding Force | 180kg(350Lbs) | Suitable | Wooden door,Glass door,Metal door,Fireproof door |
| Input Voltage | DC12V/DC24V | Operating Temp | -10~+55℃(14-131F) |
| Current | 12V/300mA DC24V/150mA | Humidity | 0~90%(non-condensing) |
| Cover Finish | Anodized aluminum | LED | Red(unlocked)Green(Locked) |
| Lock Finish | Zinc |
