CR280D -S(LED)Surface Mounts Duble Door Locks
- Holding Force280kg(600Lbs)
- Input Voltage12/24VDC
- CurrentDC12V/460mAx2 DC24V/230mAx2
CR280D CR280D-S(LED)
| Holding Force | 280kg(600Lbs) | Humidity | 0~90%(non-condensing) |
| Input Voltage | 12/24VDC | LED | Red(unlocked)，Green(Locked) |
| Current | DC12V/460mAx2 DC24V/230mAx2 | Signal Output | Lock signal(NO/NC/COM) |
| Cover Finish | Anodized aluminum | Size(mm) | 550L*47W*25H |
| Lock Finish | Zinc | G.W.(kg) | 4 |
| Armature Plate Finish | Zinc | N.W(kg) | 3.66 |
| Suitable | Wooden door,Glass door,Metal door,Fireproof door | PCS/CTN | 6 |
| Operating Temp | -10~+55℃(14-131F) |
CR280GB
| Holding Force | 280kg(600Lbs) | LED | Red(unlocked)，Green(Locked) |
| Input Voltage | 12/24VDC | Signal Output | Lock signal(NO/NC/COM) |
| Current | DC12V/460mAx2 DC24V/230mAx2 | Size(mm) | 550L*47W*25H |
| Cover Finish | Anodized aluminum | G.W.(kg) | 4 |
| Lock Finish | Zinc | N.W(kg) | 3.66 |
| Armature Plate Finish | Zinc | PCS/CTN | 6 |
| Suitable | Wooden door,Glass door,Metal door,Fireproof door | Humidity | 0~90%(non-condensing) |
| Operating Temp | -10~+55℃(14-131F) |
