CR380D-S(LED)Surface Mounts Duble Door Locks
- Holding Force380kg(800Lbs)
- Input Voltage12/24VDC
- Current12V/480mA*2 or 24V/240mA*2
| Holding Force | 380kg(800Lbs) | LED | Red(unlocked)，Green(Locked) |
| Input Voltage | 12/24VDC | Signal Output | Lock signal(NO/NC/COM) |
| Current | 12V/480mA*2 or 24V/240mA*2 | Size(mm) | 570L*55W*29H |
| Cover Finish | Anodized aluminum | G.W.(kg) | 5.26 |
| Lock Finish | Zinc | N.W(kg) | 5.03 |
| Armature Plate Finish | Zinc | PCS/CTN | 6 |
| Suitable | Wooden door,Glass door,Metal door,Fireproof door | Humidity | 0~90%(non-condensing) |
| Operating Temp | -10~+55℃(14-131F) |
