CR-180(S)urface Mounts Duble Door Locks
- Holding Force180kg(350Lbs)
- Input Voltage12/24VDC
- Current300mAx2/12VDC or 150mAx2/24VDC
| Holding Force | 180kg(350Lbs) | Humidity | 0~90%(non-condensing) |
| Input Voltage | 12/24VDC | LED | Red(unlocked)，Green(Locked) |
| Current | 300mAx2/12VDC or 150mAx2/24VDC | Signal Output | Lock signal(NO/NC/COM) |
| Cover Finish | Anodized aluminum | Size(mm) | 340L*42W*21H |
| Lock Finish | Zinc | G.W.(kg) | 2.4 |
| Armature Plate Finish | Zinc | N.W(kg) | 2.02 |
| Suitable | Wooden door,Glass door,Metal door,Fireproof door | PCS/CTN | 6 |
| Operating Temp | -10~+55℃(14-131F) |
