CR600DSurface Mounts Duble Door Locks
- Holding Force600kg(1200Lbs)
- Input Voltage12/24VDC
- Current12V/600mA*2 or 24V/300mA*2
| Holding Force | 600kg(1200Lbs) | LED | Red(unlocked)，Green(Locked) |
| Input Voltage | 12/24VDC | Signal Output | Lock signal(NO/NC/COM) |
| Current | 12V/600mA*2 or 24V/300mA*2 | Size(mm) | 530L*71W*4H |
| Cover Finish | Anodized aluminum | G.W.(kg) | 9.2 |
| Lock Finish | Zinc | N.W(kg) | 9 |
| Armature Plate Finish | Zinc | PCS/CTN | 3 |
| Suitable | Wooden door,Glass door,Metal door,Fireproof door | Humidity | 0~90%(non-condensing) |
| Operating Temp | -10~+55℃(14-131F) |
