Dynamic QR code access control, Bluetooth access control, dynamic QR code reader, Free API APP,Support firmware modification
- Reading Type: QR Code , Bar code , IC Card ,NFC Card,DES Fire(CPU Card),EV2, Bluetooth（optional ）
- Communication interface: TCP, RS485, RS232 WG 26 , WG34
- Support: cloud data
Functional Features
Support QR code /IC card/ID card/Bluetooth
Support WIFI communication, no wiring
Support mobile phone Bluetooth door, no pairing
Supports offline whitelist verification
Support infrared anti-demolition alarm
| Reading Angle | Angle 360°, elevation Angle ±55°, deflection Angle ±55° | Ambient light | Direct sunlight at noon, micro light source at night |
| Scanning Angle | 72° (horizontal), 54° (vertical), 84° (diagonal) | Relative humidity | 5% to 95% (non-condensing) |
| Reading speed | < 200 ms | Communication mode | Ethernet /485 |
| Storage capacity | The number of offline users is 40,000 (QR code 20,000 / card 20,000), and the number of offline records is 60,000 | Identification mode | Qr Code /IC card/ID Card/Bluetooth (optional) |
| Recognition distance | The identification distance is 5-30cm for QR code, 3-10cm for IC card, 2-6cm for ID card, 0-5m for Bluetooth | Apparent dimension | 115.08 * 75.1 * 15 mm |
| Display screen | OLED 0.96 display | Anti-demolition alarm | Support local alarm and signal output, can be transmitted to the background in real time |
| Input power supply | DC12V500mA (Support 5~24v) |
