CR-2FB QR Access Controller &QR Reader
- DC 12V 1000MA
- EM card or Mifare Card for choose
- Identify paper or screen QR Code
Download
| Size(L*W*H) | 86*86*18mm | Reading directions | Camera centric slant 45° |
| Material | Case:PC Identify panel:tempered glass | Reading speed | <200ms |
| Interface | Wiegand26,34,RS485,RS232,optional | Reading range | 0-20CM |
| Decoding support | QR code,one dimensional code | Reading feature | auto-induction,beep hint |
| Voltage | Support 4-15V Wide voltage input | Light source | With LED light source itself,anti-highlight interference |
| Current | 800mA | Decode Mode | Image decoding |
| Application environmet | Temperature:-20~70ºC Humidity:10%~90% | Reading range | 3-6CM |
| Operate system | Windows(xp 7 8 10),Linux | Reading card type | EM or Mifare card |
| Indicating status light | Red-Work,Green-Feedback,Light Green-Internet |
Features:
1.DC 12V 1000MA
2.EM card or Mifare Card for choose
3.Identify paper or screen QR Code
4.Support 26/34 weigand output to third party Access Control system
5. RS232,RS485,virtual keyboard,virtual Serial port,HTTP
output,MQTT output optional
Specification:
Item Type:Card Reader
Optional Style:ID Card,IC Card
Material:Zinc Alloy+Acrylic Card
Reader Type:for EM card
Barcode Type:QR,barcode
Communication Method:For Wiegand 26/34/RS232/RS485/TTL
Working Frequency:125(Khz)
Decoding Mode:Image decoding
Reading Direction(barcode):45°inclined plane with the lens as the center
point
Scan Coding Features:Automatic induction,buzzer prompt
Working Voltage:8-12V
Working Current:800mA
Card Reading Distance(card):Approx.3~6cm/1.2~2.4in
Reading Distance(QR):Approx.0~20cm/0~7.9in Reading
Speed:<200ms
Operating System:For WindowsXP/7/8/10)/Linux
Light:Standby state(blue light is on normally),card reading/scanning
state(green light is on for about 0.5s)
Built-in Horn:Buzze
